CIRAS-3 Main Console (Continued)
Power Supply
Two internal, rechargeable 7.2V Li-ion battery pack providing up to 12
hours continuous use. Power supply/charger included. Please note
that the system is capable of being powered by one battery pack for up
to 6 hours continuous use.
Operating Temperature
Range
0-50
o
C, non-condensing. In dirty environments, external air filtration
may be required.
Enclosure
Rugged, ergonomic, lightweight aluminum with polyurethane base.
Dimensions
28 cm (W) x 14.5 cm (D) x 24 cm (H)
Weight
4.3 kg (including 1 battery pack).
4.5 kg (including 2 battery packs)
PLC3 Leaf Cuvettes
Construction
• Handle - Aluminum
• Leaf Gasket - Closed cell foam
• Impeller – Aluminum fan blade
Window
PLC3 Universal – Glass IR interference filter (Calflex)
• 25 mm x 7 mm (1.75 cm
2
)
• 18 mm diameter (2.5 cm
2
)
• 25 x 18 mm (4.5 cm
2
)
PLC3 Narrow – Glass IR interference filter (Calflex)
PLC3 Conifer – Scratch resistant glass
LCD Display
2 x 16 character LCD for display of user defined parameters
Keypad
Two tactile feel keys for recording and LCD selection
PAR Sensor (Internal)
PLC3 Universal – 2 miniature, silicon photodiode sensors
PLC3 Narrow and Conifer – 1 miniature, silicon photodiode sensor
• Response: 400-700 nm
• Range – 0-3000 µmol m
-2
s
-1
• Precision – 10 µmol m
-2
s
-1
