Configuring the Local Network
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|114
The Manually define internal networks checkbox shows.
4. To use Automatic Learning, do not select Manually define internal networks and click
Apply.
5. To use your own network definitions, select Manually define internal networks.
The network definition features and table show.
6. Click New.
7. Enter the network IP address.
8. Enter the subnet. An internal network can be a 255.255.255.255 subnet, for one host.
For example, to monitor the traffic after the router, enter the IP address of the Default
Gateway and the 255.255.255.255 subnet.
9. Click Apply
The Internal network you defined (with Monitor Mode in the name) shows in the list of
interfaces.
Note - You can configure multiple local networks to be in monitor mode at the same time.
After you configure monitor mode:
1. Go to Device > Advanced Settings.
2. Turn off Anti-Spoofing.
To configure monitor mode in Gaia Clish:
1. To define a port for Monitor Mode:
set interface <Port Name> monitor-mode
2. To configure Monitor Mode Automatic Learning, disable user-defined networks:
set monitor-mode-configuration use-defined-networks false
3. To configure Monitor Mode with user-defined networks:
add monitor-mode-network ipv4-address <IP Address> subnet-mask
<Mask>
set monitor-mode-configuration use-defined-networks true
4. To see user-defined Internal networks:
show monitor-mode-network
