Restoring Factory Defaults
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|454
To switch between Bypass-mechanism modes:
n
Use Clish or WebUI (see below for details).
Or
n
Use the Bypass push button on the side of the 1595R appliance.
In Active mode, pressing the button for more than 5 seconds switches the mode to
Force-Bypass.
In Force-Bypass mode pressing the button for more than 5 seconds, switches the mode
to Active.
The Bypass LED indicates the current bypass status when power is on. When the LED is on,
Bypass is activated. If the LED is off, Bypass is off.
Note - When using the button to switch modes, the status will not be saved in the
configuration and the mode will switch back to the UI configured mode after a reset or
power down.
When the mode is set to Active: After power is restored or after a reset, the appliance reboots
and the system maintains the bypass between the DMZ/LAN4 ports until the Security Policy is
activated. Once the Security Policy is activated, the system will set the Bypass to the mode
configured by UI.
When the mode is set to Bypass: After power is restored or a hardware/software reset, the
DMZ-LAN4 port connection is still bypassed until you reconfigure the mode and the software
system is valid.
Configuring Bypass mode in the WebUI
1. Go to Device >Advanced Settings.
2. In the search field, enter "fonic."
3. The Fonic settings - Mode attribute appears. Double-click the attribute name.
4. In the attribute window that opens, select or clear the checkbox to change the mode from
Active to Bypass mode.
5. Click Apply.
Configuring Bypass mode in Gaia Clish
To display the current (Fonic) Bypass configured mode:
show fonic-settings advanced-settings
To switch between Active and Bypass mode:
set fonic-settings advanced-settings mode
