Managing the Device
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|97
If you are in an Annex L system, in Advanced Settings, you must enable the Annex L and
disable the Annex J/M.
If you are in an Annex M system, in Advanced Settings, you must enable Annex J/M and
disable the Annex L.
In all other Annex systems, no changes are needed to the default configuration.
Notes:
n
Multiple Internet connections can be established over a single VDSL/ADSL
connection carrying PTM traffic or in the case of WAN and DMZ interfaces.
n
Only one Internet connection can be established over a VDSL/ADSL
interface carrying ATM traffic or a USB interface.
n
One IPoE or PPPoE connection can be established over ATM running over
the DSL interface.
n
A single IPoE connection or multiple PPPoE connections can be established
over one untagged DSL interface carrying PTM traffic.
n
A single IPoE connection or multiple PPPoE connections can be established
over one VLAN tagged DSL interface carrying PTM traffic.
n
A single DHCP or Static IP connection can be established over a USB
interface.
n
A single DHCP or Static IP connection or multiple PPPoE connections can be
established over one untagged or one VLAN tagged WAN or DMZ interface.
n
When all the ADSL standards are turned off in the Advanced Settings and
you can only connect using the VDSL2 standard, the VPI, the VCI and the
encapsulation options still appear even though they are not used to open an
Internet connection.
Monitoring
Note - This section applies to both IPv4 and IPv6 connections.
On the Internet Connectivity page, click Connection monitoring...
Procedure
The Monitoring Servers table shows the configured connections:
n
Connection - Name. For example, Internet1.
n
Server Name
n
IP address
n
Packet Loss
n
Failures
