Configuring the Local Network
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|116
If you do not see the Monitor Mode option:
1. Run this command in Gaia Clish:
set monitor-mode-configuration allow-monitor-mode true
2. Select an interface in WebUI and click Edit.
Monitor Mode is now added to the options list.
For more information on monitor mode, see sk112572.
Mirror Port
All traffic that goes through one or more LAN ports of the appliance can be duplicated into one
designated mirror port. For example, all traffic that passes through LAN1 and LAN2 is
duplicated into LAN5, which is configured as the mirror port. You can only configure one mirror
port at a time.
Use Case – If an external device is connected to the mirror port, it receives all traffic that goes
through LAN1/LAN2 of the appliance. This enables you to monitor traffic that goes through the
appliance from the external device.
The mirror port is the opposite of the existing monitor port feature, in which the traffic from an
external source such as a network switch or router goes into the (WAN) port of the appliance,
so the appliance can inspect the traffic going through the external source.
To configure a mirror port:
To configure a mirror port:
1. In the Device > Local Network page, select the designated mirror port and unassign it:
a. Click Edit.
The Edit LAN window opens.
b. In the Configuration tab, in the Assigned to field, select Unassigned.
c. Click Apply
2. In the Local Network table, select the LAN port you want to duplicate and click Edit.
The Edit LAN window opens.
3. In the Port Mirroring section of the Advanced tab, select the checkbox Assign to mirror
port.
4. In the Port field, select the mirror port from the drop-down menu.
