Managing the Device
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|85
Notes:
l
Only one cellular modem is supported.
l
Only customers with an approved RFE will be supported with the external
modem specified in the RFE.
IPv6 Connection Types
IPv6 connection types
Important - The device can have only a single IPv6 Internet connection.
n
Static IPv6 - A fixed (non-dynamic) IP address.
n
Obtain automatically (DHCPv6/SLAAC) - In both Dynamic Host Configuration Protocol
(DHCP) and Stateless Address Auto Configuration (SLAAC) the user does not set the IP
as this is handled by the router/DHCP server. DHCPv6 issues a full IP address. SLAAC
issues an IP address prefix, and the gateway completes the rest of the address
according to discovery protocols.
n
PPPoE (IPv6 only) - A network protocol to encapsulate Point-to-Point Protocol (PPP)
frames inside Ethernet frames. It is used mainly with DSL services where individual
users connect to the DSL modem over Ethernet and Metro Ethernet networks.
n
PPPoE (IPv4/IPv6) - Same as PPPoE (IPv6 only), but the user must first configure a
type IPv4 PPPoE internet connection on the same interface. Use this option when the
ISP provides both IPv4 and IPv6 addresses through the same PPPoE connection. This
prevents the need to define the same dialer connection details more than once.
n
IPv6 Bridge - A Layer 2 bridge between internal and external networks, containing both
IPv4 and IPv6 addresses (or just IPv6) to make the gateway reachable through the
bridge in a dual stack/pure IPv6 network.
Supported as static WANIP and DHCP.
To configure an Internet connection over the DMZ port:
1. On the Configuring Internet Connectivity page, click New to create a new Internet
connection.
The New Internet Connection window opens in the Configuration tab.
2. For Interface, select DMZ.
n
For a DSL over DMZ Connection, select SFP-DSL.
n
For a non-DSL connection, select RJ45/SFP-Fiber.
3. Click Save.
