Deploying from a USB Drive or SD Card
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|32
Suggested Workflow - Configuration File Error
This section contains a suggested workflow that explains what to do if there is an error with the
configuration file on a USB drive. Use the set property USB_auto_configuration
command when you run a configuration file script on a configured appliance.
1. The USB drive with the configuration file is inserted into a USB port on the Quantum
Spark Appliance.
2. The USB LED on the front panel blinks red. There is a problem with the configuration file
script.
Sample console output displaying an error:
Booting Check Point RD-6281-A User Space...
INIT: Entering runlevel: 3
........sd 2:0:0:0: [sda] Assuming drive cache: write through
sd 2:0:0:0: [sda] Assuming drive cache: write through
.....................................................
System Started...
Start running autoconfiguration CLI script from USB2 ...
Error.
autoconf.00-1C-7F-21-07-94.2011-07-21.1248.log was copied to
USB2
3. The log file is created and contains the configuration details.
n
The log file is called: autonconf.<MAC Address>.<timestamp>.<log>
n
The log file is created in the USB root directory and in /tmp on the appliance.
4. Analyze the log file to find the problem.
If you cannot repair the configuration file:
1. Remove the USB drive.
2. Run the CLI command:
restore default-settings
3. Connect to the Web UI and use the First Time Configuration Wizard to configure the
appliance.
