SD-WAN
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|234
d. Configure at least two internet connections - one for each ISP:
i. Click New.
The New Internet Connection window opens.
ii. On the Configuration tab:
i. In the Connection name field, enter the applicable name for this
connection.
ii. In the Interface field, select the applicable interface.
iii. In the Connection type field, select the applicable type.
iii. On the Connection Monitoring tab:
Select Automatically detect loss of connectivity to the default gateway.
iv. On the Advanced tab:
i. Click SD-WAN Settings to expand the section.
ii. In the Upload speed (Mbps) field, configure the values provided by
the ISPs for the upload speed of the Internet connection. For
example, Bezeq gives an upload speed of 100 MB.
iii. In the Download speed (Mbps) field, configure the values provided
by the ISP for the download speed of the Internet connection. For
example, Bezeq gives a download speed of 1000 MB.
SD-WAN uses all the links that meet the thresholds and fives weights
proportionally to the configured upload/download speed.
iv. Select the checkbox This internet connection will be a part of SD-
WAN.
v. For the checkbox This internet connection will be set as backup in
SD-WAN, select this only for links that are expensive or of poor
quality. For example, Cellular networks have a plan, and if you
exceed your limit it can be costly. In the MPLS network, you pay per
use.
v. Click Save.
For more information see
"Configuring Internet Connectivity" on page74
.
Notes:
n
You can also configure a new SD-WAN connection on the Access
Policy >SD-WAN page.
n
To navigate directly from the SD-WAN page to the Device
>Internet page, click Manage and monitor links.
