Quantum SPARK 1500 - Page 411

Configuring External Log Servers
R81.10.X Quantum Spark 1500, 1600, 1800, 1900, 2000 Appliances Locally Managed Administration Guide|411
2. Enter the Management Server IP address.
This IP address is used only to establish trusted communication between the appliance
and the Security Management Server.
3. In SIC name, enter the SIC name of the Log Server object defined in SmartConsole.
These are the options to get this name:
n
Option 1:
a. Connect with Database Tool (GuiDBEdit Tool) (see sk13009) to the Security
Management Server.
b. From the Tables tab, expand Table > Network Objects.
c. In the right pane, locate the Log Server object.
d. In the bottom pane, locate sic_name.
n
Option 2:
Run this CLI command on the Log Server in the Expert mode (use SSH or console
connection):
$CPDIR/bin/cpprod_util CPPROD_GetValue SIC MySICname 0
Copy the SIC name value and paste it into the SIC name field on this page.
4. In Set SIC One-time Password, enter the same password that was entered for the
Security Management Server and then enter it again in the Confirm SIC One-time
Password field.
Note - You cannot use these characters in a password or shared secret: { } [
] ` ~ | ‘ " \ (maximum number of characters: 255)
5. If the Log Server is not located on the Security Management Server, select Log server
uses different IP address and enter the IP address.
6. Click Apply
Important:
n
After successful configuration of the external log server, any changes you
make in the WebUI configuration on this page requires reinitialization of
the SIC in SmartConsole. If you do not reinitialize SIC in SmartConsole,
connectivity to the log server can fail.
n
To see the logs, you must connect with SmartConsole to the dedicated
Log Server (and not the Security Management Server).
