Programming and Operation, continued
21
8. Active/Passive
indicates whether a current Program is Active (A) or Passive (P).
9. Run Every
shows the selected irrigation days, from 1-14.
1 0. Repeat
shows how many times (up to 99 times) irrigation Programs Repeat.
11. First
shows the year, month and day a Schedule begins.
12. Pause
shows how many minutes you want a Program to Pause between Repeat Programs, before resuming
with the next Program.
13. Sprinkler Icon
“sprinkles” when an irrigation Schedule is running.
14. (Search) Labels
use the buttons associated with the Sch labels to move up and down through the 11 stored Programs.
15. (Schedule) Label
use the button associated with the Sched label to set up specific irrigation Schedules.
16. Label
use the button associated with the Menu label to enter the Main Menu.
17. Label
use the button associated with the Auto label to set the controller to the Auto mode. A menu displays allowing
you to Pause the irrigation Schedule and manually start the decoders.
18. Label
use the button associated with the Manual label to enter a menu where you can manually start irrigation
programs or decoders and Pause a running Program.
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sched Menu Auto Manual
Sch Sch
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sch Sch
Sched Menu Auto Manual
10
13
12
7
8
3
6
2
5
1
4
9
11
14 15 16
17
18
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sched Menu Auto Manual
Sch Sch
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sched Menu Auto Manual
Sch Sch
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sched Menu Auto Manual
Sch Sch
Program 1 Total 0:05 09:48:00
2 MTWTFSSMTWTFSS (2) 13:50 100% A
Run every 5. Day Repeat 6 times
First 2002-03-26 Pause: 1 Min.
Sched Menu Auto Manual
Sch Sch
