Programming and Operation, continued
33
9. Use the right arrow to move to the Limit field
and select OK to activate it.
10. Use the up and down arrows to set the limit and
select OK.
11. Use the right arrow to move to the second
alarm field and select OK to activate it.
12. Use the up and down arrows to choose between
the Leak and Disable and select OK.
Note: If you choose Disable, select OK and then
select - to exit the screen.
13. If you choose Leak, select OK.
14. Use the right arrow to move to the Limit field
and select OK to activate it.
15. Use the up and down arrows to set the limit and
select OK.
16. Use the right arrow to move to the Action field
and select OK to activate it.
17. Use the up and down arrows to decide what
action you want to take place if the leak
threshold is reached and select OK.
18. Use the right arrow to move to the Object field
and select OK to activate it.
19. Use the up and down arrows to choose amongst
Decoder, Schedule or Pump to be affected by the
defined alarm condition and select OK.
20. Use the right arrow to move to the Object ID
field and select OK to activate it.
21. Use the up and down arrows to choose the
specific Decoder, Schedule or Pump to be
affected by the defined alarm condition and
select OK.
22. Select - to return to the Main Menu.
Setting up an auxiliary sensor
An auxiliary sensor works with rain or alarm
sensors. If the rain sensor is installed far from the
controller or if your system uses a pump alarm,
you will also need an auxiliary sensor activated by
a sensor decoder. Remember, auxiliary sensors
can only tell if a switch is open or closed. Once an
auxiliary sensor activates, irrigation stops.
1. From the Sensor Decoder menu, move the
indicating arrow to 5. Aux. Sensor Decoder
Address and select OK. The two alternating
blinking markers indicate the Sensor Decoder
Address field is ready for you to program in the
Address.
2. Use the up and down arrows to match
the Decoder your system is using for the
Auxiliary Sensor.
Note: The Address should be recorded on the
irrigation drawings.
3. Select OK to store the Address and move the
markers to the Active field. A blinking black box
indicates the field is ready for you to program.
Not Install is the default setting.
4. Use the up and down arrows to select either
Normally open or Normally closed.
Note: Select Normally open if the auxiliary sensor
is open all the time. Select Normally closed if the
auxiliary sensor opens only when it receives a signal.
5. Select OK to return to the Sensor Decoder
menu.
6. Moving the indicating arrow to 6. Return, and
selecting OK, or selecting minus (-) returns you
to the Set-up Data menu.
