3352.4
BOUNDARY
Alarm
This is a very special type of alarm and is useful when there is an area that
you need to avoid. A typical use would be to mark an area bounded by
shoals or rocks. The BOUNDARY alarm distance then becomes the safety
margin that you want to maintain from the hazardous area.
The
BOUNDARY
alarm feature can be
put into use when you enter the posi-
tion co-ordinates of each end point of
a line that bisects the hazard area as
waypoints into the
waypoint
memo-
ries. Now we can use one of the avail-
able Route Plan memories to hold the
two points.
wFr*
,
To set a boundary alarm, the user should be familiar with entering
way-
points and making a route plan. Although the specific instructions are given
below for accomplishing the task of making a Boundary alarm, it is recom-
mended that sections involving
Waypoint
entry and Route plans be re-
viewed, ifnecessary.
1. Enter the end points of the boundary into
NAVIGATION MENU
waypoint memories.
+
SATELLm STATUS
and
selectl~~vf~~‘rt~~I
.
Select
Press/
MAKEROuTE/.
+
NAVIGATE SETUP
3. Select a route plan
#
using the
A
(up) or
+
STORE WAYPOINTS
v
(down) direction keys and press
I[.
+
ROUTE
PLANS
4. Press the
I
softkey
and then enter the
memo
number
ofthe
first endpoint X,X,X. Press
th
eir
softkeyagain and then enter the memory
1
INC
PRESS M EN U TO RETURN
number of the second endpoint of the boundary line X,X,X. Now the Route
Plan is made. Press the
IMENV]
key to leave the MAKE ROUTE menu.
5.
Press1
MENU/again
and
select-l.
Select[~[again.
This time
press1
SELECT
ROUTE1
.
6. Select the route plan # containing the two points for the Boundary line
with the
A
I
v
key. Press
them
(7
softkey)
and press
m.
The
OPERATION 66
