100
ISSUE
SOLUTION
Maps do not cache/save
1. Make sure that the active network has WiFi
selected.
2. Make sure
that proper procedure was
followed in the
Offline Maps
screen:
3. Touch the Teal Settings icon.
4. Change the
Active network
from Drone to
WiFi.
5. Login into the WiFi
system with the
appropriate login credentials.
6. Slide the
Settings
screen all the way to the
right to open the QGC app.
7. Touch the
Main menu icon
in the top left of
the screen.
8. Select
Settings
at the bottom left of the
screen.
9. Select Offline Maps.
10. Select
Add
New Set.
11. Set and zoom to the area that you would like
to save.
12. Create a name for map set in the
Add New Set
field.
13. Set the map type.
14. Check the
Fetch Elevation Data
box to
include elevation data with the tile set.
15. Select
Download
when finished.
16. Touch the
Main menu icon
in the top left of
the screen.
17. Select the
Fly
button.
18. Touch the Teal Settings icon.
19. Change the Active network to
Drone
from
WiFi.
20. Once the GCS
acquires the GPS signal, the
map screen will automatically load that tile
set.
Maps are not saved or imported
on the GCS.
