During the hot battery LED sequence:
1. The first LED light blinks for two seconds.
2. The lights display the battery’s level of charge for 2.5 seconds.
3. All LED lights turn off, indicating the battery is off.
4. The battery does not charge.
When charging batteries, make sure the LED lights are indicating the battery is charging.
Teal purposefully designed the power source for the AV and the TAC to use the exact
same Teal Performance Battery Pack and Teal Battery Charger for both systems.
13.4.3 BATTERY COMPONENTS
The Teal Performance Battery Pack consists of six (6) Sony VTC6 18650 lithium-ion cells
wired in series to produce a total nominal voltage of 22.2 volts (3.7 VDC per cell). The
output voltage ranges from 21.6 VDC (3.6 VDC per cell) to a maximum of 25.2 VDC (4.2
VDC per cell). The cells have a capacity of 3 Ah (amp-hours), producing a total nominal
energy of 66.6 Wh (watt-hours).
This results in approximately 60 usable Wh from the pack, which equates to flight time of
up to 30 minutes for the AV and up to 8 hours of operation on the GCS.
The AV and the TAC do not support a
battery pack hot-swap. Be sure to power
down the battery pack before removing
and replacing it.
Pack dimensions are: 5.03” L x 2.86” W x 0.96” H (127.68 mm L x 72.67 mm W x 24.5 mm H).
Each pack weighs approximately 0.84 lbs (380 g).
BATTERY POWER / STATUS BUTTON
Quickly push-and-release (tap) the button to briefly indicate the pack’s state-of-charge.
Press-and-hold for four (4) seconds to power off and on. The middle LED in the charge level
meter stays lit when the pack is powered on.
13.4.4 BATTERY LED INDICATORS
The battery pack has a 5-LED bar graph to indicate state-of-charge and power status
indicated in 20% increments.
