RED CAT TEAL 2 - Pre-Flight Checklist; Operations Checklist

41
4.11 PRE-FLIGHT CHECKLIST
An automated pre-flight checklist in FLY TOOLS can be used to run through standard
checks to ensure that the AV is configured correctly and is safe to fly. Enable the tool by
navigating to Application Settings > General > Fly View and select the Use Preflight
Checklist checkbox. The tool will then be added to the Flight Tools box. Touch the
checklist icon from the Fly view to open the checklist.
4.11.1 OPERATIONS CHECKLIST
Check air space for restrictions and obtain authorization as required by the appropriate
authorities having jurisdiction and follow all FAA, federal, and local rules and regulations.
Verify the airframe and each payload, propulsion, and battery system is air-worthy and not
damaged.
*Range estimates represent maximum command and control (C2) link
performance in optimum environmental conditions. For safety of operations,
the AV must always be operated within the RPIC’s line of sight.
** Remote ID is reliant on georeferenced position from the GPS receivers onboard the aircraft and TAC.
Loss of GPS reception, or GPS dilution may affect the performance of the Remote ID system, and
subsequently the adherence of the aircraft to 14 CFR §89.310(h). AV pilots must adhere to the
limitations and procedures described on page 48
of this document to avoid interruption of operation
and potential RID failure.
The AV is designed for IP-53.
TEAL 2 SYSTEM
(sUA,GCS, BATTERY PACKS)
Operating Temperature
Range
-32 °F to 110 °F (-35.6 °C to 43.3 °C)
Note: In low temperatures (32 °F (0 °C) or below),
pre-heat the battery by placing it on the charger
before flight.
Operating Humidity
Range
10% to 90% RH, non-condensing
CS SYSTEM
Operating Frequencies
1.8 GHz
2.3 GHz
2.4 GHz
Tablet Display
Resolution
WUXGA (1920 x 1200)
Tablet Display
Brightness
550 nits (outdoor conditions only)
Tablet Interaction
Glove Mode
Wi-Fi
802.11 a/b/g/n/ac 2.4 or 2.3 G+5 GHz, VHT80
CS GNSS
GPS, GLONASS, GALILEO, BEIDOU
