This may result in:
• Partial or complete loss of the airframe, camera, gimbal, arms, motors,
payloads, and props.
• Partial or complete loss of data.
• Damage to property on the ground from AV impact.
• Significant injury or death of persons or damage to property struck by the
falling AV.
4.10 SYSTEM CAPABILITIES / OPERATING LIMITATIONS
TEAL 2 AV
Flight Time
30+ minutes (US Standard Atmosphere 1976, which is 59F,
Sea Level, 29.92 Barometric Pressure)
Weight
2.75 lbs (1.25 kg)
Flight speed
10 m/s (23 mph)
Top Horizontal Speed
32.8 ft/s (10 m/s, 23 mph)
Maximum Vertical
Speed
8.2 ft/s (2.5 m/s)
Maximum Servicing
Ceiling
10,000 ft (3,048 m) MSL
Operation Temp Range
-32 to 110 F (-35.6 to 43.3 C)
Wind Limits
18 mph (16 kn) Sustained to 25 mph (22 kn) Gusts
Max Range from
controller
Up to 5 km
Signal Range
1.8 GHz line of sight: up to 2.17 miles (3.5 km)*
2.3 GHz MIMO line of sight: up to 1.86 miles (3 km
)*
2.4 GHz MIMO line of sight: up to 1.86 miles (3 km)*
Maximum Auxiliary
Payload Weight
75 grams
Operating Frequencies
1.8 GHz
2.3 GHz
2.4 GHz
Encryption
AES 256
Protocol
MAVLink
EO Recording
4,000 x 3,000 @ 15 FPS
Video Format
H.264 Transport Stream and MP4
Gimbal Range
Pitch: -120° to + 120°
Roll: -35° to +35°
IR Sensor
FLIR Boson, 640 x 512 Pixels
IR Video Recording
640 x 512 @ 30 FPS
sUA GNSS
L1 GPS+GLONASS with SBAS and QZSS enabled
