92
The Smart Charge Adapter has an internal cooling fan that automatically turns on when
power is applied to keep the smart charger electronics operating safely across the
specified operating temperature range.
The battery pack is simply inserted onto the charger via mating slots in the battery pack,
and the side latches on the battery pack securely lock it into place.
Charger dimensions are: 3.65” L x 3.52” W x 1.80” H (92.7 mm L x 89.4 mm W x 45.7 mm H).
Each charger weighs 0.35 lbs (158 g).
13.6 CHARGER EXTERNAL POWER SUPPLY
The power supply for the Teal Battery Charger is an external cord-to-cord brick style
switching power supply with a universal voltage input. It has a captive DC power cable and
a removeable USA NEMA 5-15P to IEC 320 C13 AC power cable.
The power supply may be operated from AC voltages ranging from 100-240 VAC. The
removeable AC cord can be replaced with an appropriate cord for that particular region.
The supply power unit is a fully sealed enclosure complying with IP32 environmental rating
and operates in temperatures ranging from 32 °F to 140 °F (0 °C to 60 °C). It is approved
to international medical and IT safety standards. The output power is 120 W, the output
voltage is 25.2 V, and output current is 5.0 A (±5%).
13.7 BATTERY WARNINGS AND CAUTIONS
Always power down the AV and the GCS before removing and
replacing their battery packs.
Charge within the temperature range of 0 °C to 45 °C (32 °F to 113 °F).
Do not operate the charger in direct sunlight to avoid exceeding
temperature limits.
After charging, remove the battery from the charger to prevent
prolonged heating and damage to the battery.
Unplug the charger power supply when not in use to prevent
unnecessary heating and wear on electrical components.
Charge battery packs at least once every three months to prevent over-
discharge and possible permanent damage.
