2.8 PAIR AND CONNECT THE GCS WITH THE AV
Most AVs and GCS kits are paired in the factory. The system remembers the pairing and
automatically connects when the Teal QGC app launches. See the pairing section in Teal 2
AV for how to pair an AV and GCS.
To verify the AV and GCS are paired and connected:
1. Power on the AV
2. Power on the GCS.
3. From the home screen, tap the Teal QGC icon.
4. If the AV is listed in the upper left corner of the screen, the AV and GCS are
connected.
If the AV and GCS are not paired, pair the AV and GCS.
To pair the AV and GCS:
1. Open the Teal Settings application.
2. Click Pair Drone +.
3. Press and hold the pair button on the back of the AV for five seconds.
4. Click Continue.
5. Select the AV to pair. Pair one AV at a time.
6. Click Pair with this device.
7. Confirm the settings.
a. Confirm the network name, password, channel, and drone range.
b. The available drone ranges are short, mid, and long. Long is the default drone
range. Do not change the drone range unless a lower power range is needed.
Drone
Range
Distance
Bandwidth
Power
Short
500m
8 MHz
7dbm
Mid
3000m
8 MHz
20dbm
Long
7500m
8 MHz
30dbm
8. Click Confirm and start pairing.
9. When pairing is successful, click Finish.
10. Click Teal QGC in the bottom right corner to return to the Fly View.
Note: To change the channel after
the AV is paired, unpair the AV.
Follow the pairing steps and change
the channel on the confirm settings
page
