Before operating multiple AVs, deconflict the RF frequencies. Each RF radio channel for
each AV should be at least 20 MHz away from the other AV frequencies. If one AV is using
5 MHz, the next AV needs to use 25 MHz.
The 1.8 GHz has channels 4-56. The 2.4 Ghz has channels 6-76.
11.2.2 LAN / DRONE
Select to connect the GCS to the AV or Wi-Fi.
11.2.3 I / O
The GCS includes a high-speed USB-C 3.1 port; future functionality and features may be
developed.
11.2.4 SAMSUNG TABLET
The GCS system uses a Samsung Galaxy Tab Active Pro tablet, which is MIL-STD-810G
certified and IP68-rated. It features a large, WUXGA (1920x 1200) resolution, 10.1”
touchscreen and is super-bright and sunlight-visible with a 550-nit rating. The audio vents
comply with the IP53 rating.
11.2.5 CS SYSTEM POWER
The main on/off system power switch for the GCS is built into the battery pack. A 4-
second press-and-hold of the battery power button turns the pack on or off.
The GCS does not support a battery pack hot-swap. Power
down both the tablet and the battery pack before removing
and replacing the battery pack from the GCS.
11.2.6 TABLET POWER
After powering on the GCS main system power via the battery button with a 4-second
press-and-hold, the tablet must then be powered on via its tablet power button with a 2-
second press-and-hold.
When the tablet power is on, a quick tap on the tablet power button puts the tablet to
sleep. When asleep, a quick tap on the tablet power button, or a double-tap on the screen,
wakes it up.
