13
Replace propellers if they are
damaged or cracked.
5. Remove the gimbal protective cover.
6. Insert and latch a fully charged battery pack into the battery compartment on the
bottom of the AV.
7. Verify both battery pack latches are fully engaged with the airframe to secure the
battery pack.
Note: CW propellers lock into place by turning them in a
CCW direction. CCW propellers lock into place by turning
Figure 1 Clockwise and counterclockwise arms and propellers.
