Pin Function
1 E1 OUT-
2 -
3 E1 IN-
4 -
5 -
6 -
7 GND
8 -
9 E1 OUT+
10 -
11 E1 IN+
12
13
14 FLOF
15
IMUX
2000E1 RFL Electronics Inc.
Pin Function
1 -
2 RS232TXD
3 RS232RXD
4 -
5 GND
6 -
7 -
8 -
9 -
Pin Function
1 TIMIN-
2 TIMIN+
3 -
4 -
5 TIMOUT-
6 TIMOUT+
Pin Function
1 E1-IN-
2 E1-IN+
3 -
4 E1-OUT-
5 E1-OUT+
6 -
7 GND
8 GND
Figure 2-13. MA-270R pinouts
MA270R
E1 RS232
E1 IN EXT TMG
E1
E1 OUT
8
15
9
1
BNC
8
1
5
9
6
1
6
1
DB-15
Male
DB-9
Male
6-Position
Modular
Jack
BNC
RJ48C
