Pin Function
1 E1-IN-
2 E1-IN+
3 -
4 E1-OUT-
5 E1-OUT+
6 -
7 GND
8 GND
IMUX 2000E1 RFL Electronics Inc.
Pin Function
1 TIMIN-
2 TIMIN+
3 -
4 -
5 TIMOUT-
6 TIMOUT+
Pin Function
1 -
2 RS232TXD
3 RS232RXD
4 -
5 GND
6 -
7 -
8 -
9
-
Figure 2-12. MA-278 pinouts
MA278
E1
EXT
TMG
RS-232
8
1
6
1
5
1
9
6
RJ48C
6-Position
Modular
Jack
DB-9
Male
