Table 6. Remote Configuration Settings (P Codes)
P Code
Digit(s) and Switch
Equivalent
Bit Value Description
SRVC SERVICE ON/OFF ON Turns service on (module enabled)
OFF Turns service off (module disabled)
P1a
B00000000
---↑↑↑↑↑
TIME SLOT SELECT
1 to 31 These five bits set the desired time slot(s). From left to right, they
correspond to t
he five time slot select switches as shown in Table 3.
P1b
B00000000
--↑-----
0
Set transmit and receive directions:
0 = Set for operation via the DI-B port of a drop/insert multiplexer.
TERM
1
1 = Set for operation in a terminal multiplexer or via the
DI-A port of a drop/insert multiplexer.
P1c
B00000000
↑↑
------
0 t
o 3 Low-speed rate select (inoperative when P2a is set to "0"):
0 = 1200 bps, 1 = 4800 bps, 2 = 2400 bps, 3 = 9600 bps
P2a
B00000000
-------↑
0
High-speed rate select:
0 = Sets data rate to 19.2 kbps and deactivates P1c
1 1 = Activates P1c, low-speed rate select
P2b
B00000000
------↑-
0
Selects buffers and timing (Note 2):
0 = Buffers out of circuit, module uses internal timing
1 1 = Buffers in circuit, module uses DTE device timing
P2c
B00000000
-----↑--
0
Ch
annel 1 clock:
0 = normal
1 1 = inverted (Note 3)
P2d
B00000000
----↑---
0
Ch
annel 2 clock:
0 = normal
1 1 = inverted (Note 3)
P2e
B00000000
---↑----
0
Ch
annel 3 clock:
0 = normal
1 1 = inverted (Note 3)
P2f
B00000000
--↑-----
0
Ch
annel 4 clock:
0 = normal
1 1 = inverted (Note 3)
P2g
B00000000
-↑------
0
Ch
annel 5 clock:
0 = normal
1 1 = inverted (Note 3)
P2h
B00000000
↑-------
0
Set l
oopback:
0 = off (Note 4)
1 1 = on
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
2. The input buffers must be used when the DTE device tim
ing is in use, so this code sets both of these
conditions.
3. These codes are active only when internal timing is selected (P5 = 0).
4. When the loopback is on, all five receive channels are looped back into the transm
itter (used for far end
loopback during end to end testing).
