“S” CODES
“S” codes appear in response to a STATUS? query. There is one S code for the DS-961DE. Like the
"P" codes, it is displayed as both a decimal and an eight-digit binary number. A typical response to a
STATUS? query looks like this:
OK
CHANNEL CARD 1, TYPE 77
UNDER REMOTECONTROL
S01 = 2 (B00000010);
Table 7 lists the meaning of the “S” codes for this module.
Table 7. Remote Configuration Settings (S Codes)
P Code
Digit(s) and Switch
Equivalent
Bit Value Description
S1a
B00000000
-------↑
0 0 = In frame
1 1 = Out of frame (Note 1)
S1b
B00000000
------↑-
0 0 = Transmit alarm (Note 2)
1 1 = No transmit alarm
1. When the card is out of frame an ALERT message is displayed.
2. When there is a transmission alarm an ALARM message is displayed.
