Table 2-8. E1 Common Module Supplementary groups and functions
Group Name Group Description Function Name Function Description
FTIM Fallback Timing FLoo Set fallback timing Loop
FInt Set fallback timing to Internal
FExt Set fallback timing to External
FThru Set fallback timing to Through
exit exit
JBUF Jitter Buffer Joff No jitter buffer
J32 Set jitter buffer to 32 bits
J128 Set jitter buffer to 128 bits
exit exit
TXYL E1 Yellow Alarm Off Yellow alarm off
On Yellow alarm on
Auto Automatic activate
exit exit
Rfrm Reset framer chip NA NA
Rcht
Reset channel configuration
tabl
e
NA NA
Rcpu Reset cpu NA NA
IMUX 2000E1 RFL Electronics Inc.
April 1, 2007 2-36 (973) 334-3100
