Table 2-9. E1 receive status functions
Group Function Description
BLNK RxYl Received Yellow. When included in the BLNK group, indicates that a Yellow Alarm
Signal is detected at the E1 input.
Received All Ones. When included in the BLNK group, indicates that an All-Ones Signal
(framed or unframed) is detected at the E1 input.
Rx11
XsJt Excessive Jitter. When included in the BLNK group, indicates that the receiver jitter
buffer has overflowed. This may indicate that the receive signal contains excessive jitter.
RVU1 RcLs Receiver Carrier Loss. When the Receiver Carrier Loss function is displayed, the bi-color
ON/OFF indicator will light to indicate the status of the E1 receiver carrier:
GREEN: The receiver has not lost carrier.
RED: T
he receiver has lost carrier.
Table 2-10. E1 timing status functions
Group Function Description
BLNK FTIM Fallback Timing. When included in the BLNK group, indicates that the transmitter is in
its fallback timing mode.
RVU1 TxRx Transmit/Receive Lock. When the Transmit/Receive Lock function is displayed, the bi-
color ON/OFF indicator will show whether the transmitter timing is synchronized to
the received E1 signal timing:
GREEN: The transmitter and receiver timing clocks are lock
ed.
RED: The transmitter and receiver timing clocks are not locked.
IMUX 2000E1 RFL Electronics Inc.
April 1, 2007 2-37 (973) 334-3100
