VOICE CHANNEL RING,
PIN #
TIP,
PIN #
MODULE 1, CHANNEL 1 1 26
MODULE 2, CHANNEL 1 9 34
MODULE 3, CHANNEL 1 17 42
MA301
Figure 1. MA-301 Module Adapter
TOP VIEW
RIBBON CABLES
MOTHERBOARD
REAR VIEW
MA301
RIBBON CABLES
MA301
Figure 2. Using an MA-301 Module Adapter with multiple RFL VF-10D modules.
