Table 3. Tx and Rx level settings, RFL VF-10D module
Tx Input
Level
Switch
Code
Switch
Code
Rx Output
RFL VF-10D RFL Electronics Inc.
June 23, 2001 12 (973) 334-3100
Level
Physical Switch Settings SW1- / SW2-
(dBm)
(1)
(Hex) (Decimal) 2 3 4 5 6 7 8
(2)
(dBm)
(1)
-26 74 116 U U U D U D D -26
-25 72 114 U U U D D U D -25
-24 70 112 U U U D D D D -24
-23 6E 110 U U D U U U D -23
-22 6C 108 U U D U U D D -22
-21 6A 106 U U D U D U D -21
-20 68 104 U U D U D D D -20
-19 66 102 U U D D U U D -19
-18 64 100 U U D D U D D -18
-17 62 98 U U D D D U D -17
-16 60 96 U U D D D D D -16
-15 5E 94 U D U U U U D -15
-14 5C 92 U D U U U D D -14
-13 5A 90 U D U U D U D -13
-12 58 88 U D U U D D D -12
-11 56 86 U D U D U U D -11
-10 54 84 U D U D U D D -10
-9 52 82 U D U D D U D -9
-8 50 80 U D U D D D D -8
-7 4E 78 U D D U U U D -7
-6 4C 76 U D D U U D D -6
-5 4A 74 U D D U D U D -5
-4 48 72 U D D U D D D -4
-3 46 70 U D D D U U D -3
-2 44 68 U D D D U D D -2
-1 42 66 U D D D D U D -1
0
(3)
40 64 U D D D D D D 0
(3)
1 3E 62 D U U U U U D 1
2 3C 60 D U U U U D D 2
3 3A 58 D U U U D U D 3
4 38 56 D U U U D D D 4
5 36 54 D U U D U U D 5
6 34 52 D U U D U D D 6
7 32 50 D U U D D U D 7
8 30 48 D U U D D D D 8
9 2E 46 D U D U U U D 9
10 2C 44 D U D U U D D 10
11 2A 42 D U D U D U D 11
12 28 40 D U D U D D D 12
13 26 38 D U D D U U D 13
14 24 36 D U D D U D D 14
15 22 34 D U D D D U D 15
16 20 32 D U D D D D D 16
17 1E 30 D D U U U U D 17
18 1C 28 D D U U U D D 18
19 1A 26 D D U U D U D 19
20 18 24 D D U U D D D 20
21 16 22 D D U D U U D 21
22 14 20 D D U D U D D 22
23 12 18 D D U D D U D 23
24 10 16 D D U D D D D 24
25 E 14 D D D U U U D 25
26 C 12 D D D U U D D 26
See notes for Table 3 on top of next page.
