Table 5. Remote configuration settings (“P” codes) for T1/E1 in normal mode
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P1 B 0 0 0 0 0 0 0 0
- - - ↑ ↑ ↑ ↑ ↑
TIME SLOT SELECT
00001 to 11000
T1 Settings
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 24
in a T1 network. See Table 8 for a complete list of
these values.
00001 to 11111
E1 Settings
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 31
in an E1 network. See Table 8 for a complete list of
these values.
B 0 0 0 0 0 0 0 0 0 Sets Channel 1 for ground start.
- - ↑ - - - - -
LOOP START 1
1 Sets Channel 1 for loop start.
B 0 0 0 0 0 0 0 0
-
↑ - - - - - -
TERM
0 This setting may be used only in a drop/insert
multiplexer. If the module is installed in a terminal
multiplexer, this digit should always be set to “1”.
If the module is installed in a drop/insert multiplexer,
set this digit to a “1” to transmit in the A direction
and receive from the B direction. Set this digit to “0”
to transmit in the B direction and receive from
the A
di
rection.
(For guidelines on setting channel module direction,
refer to the IMUX 2000 instruction manual).
1 This setting is required when the module is installed in
a terminal multiplexer.
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
. . . Not used.
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
2. Only available for E1 in normal mode. For T1 in normal mode, use DIP switches.
