RFL VF-10D RFL Electronics Inc.
June 23, 2001 20 (973) 334-3100
Table 6. Remote configuration settings (“P” codes) for T1/E1 in enhanced mode
P Code Digit(s) And Switch
Equivalent
Value
(1)
Description
P1 B 0 0 0 0 0 0 0 0
-
- - ↑ ↑ ↑ ↑ ↑
TIME SLOT SELECT
00001 to 11000
T1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 24
in a T1 network. See Table 8 for a complete list of
these values.
00001 to 11111
E1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 31
in an E1 network. See Table 8 for a complete list of
these values.
B 0 0 0 0 0 0 0 0 0 Sets Channel 1 for ground start.
- - ↑ - - - - -
LOOP START 1
1 Sets Channel 1 for loop start.
B 0 0 0 0 0 0 0 0
-
↑ - - - - - -
TERM
0 This setting may be used only in a drop/insert
multiplexer. If the module is installed in a terminal
multiplexer, this digit should always be set to “1”.
If the module is installed in a drop/insert multiplexer,
set this digit to a “1” to transmit in the A direction
and receive from the B direction. Set this digit to “0”
to transmit in the B direction and receive from
the A
direct
ion.
(For guidelines on setting channel module direction,
refer to the IMUX 2000E instruction manual).
1 This setting is required when the module is installed in
a terminal multiplexer.
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
. . . Not used.
P2 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑
TX LEVEL CHANNEL 1
0000000 to
1111111
Sets Transmit Level for channel 1 in 0.5 dB
increm
ents/decrements from 0 dB center at 1000000.
(40H)
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
. . . Not used.
P3
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑
RX LEVEL CHANNEL 1
0000000 to
1111111
Sets Receive Level for channel 1 in 0.5 dB
increm
ents/decrements from 0 dB center at 1000000.
(40H)
Increment for lower input levels.
Decrement for higher input levels
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 No delay on Channel 1
Sets Signaling Delay for channel 1.
SIGNALING DELAY 1
1 Delay on Channel 1-default setting.
Sets No Delay for channel 1.
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
