Table 8. continued - Remote configuration settings (“P” codes)
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P06
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 (+) Positive
CH2 TX
LEVEL SIGN
1 (-) Negative
B 0 0 0 0 0 0 0 0
- ↑ ↑ ↑ ↑ ↑ - -
From 000000
t
o 010011
Range is from –9.5dB to +9.5dB in 0.5dB
increments.
For exampl
e: -2.5dB = 000101, and set sign to (-).
CH2 TRANSMIT LEVEL
For exampl
e: +3.5dB = 000111, and set sign to (+).
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
… For future use
B 0 0 0 0 0 0 0 0
- - - - - - - ↑
… For Future use
P07
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 (+) Positive
CH2 RX
LEVEL SIGN
1 (-) Negative
B 0 0 0 0 0 0 0 0
- ↑ ↑ ↑ ↑ ↑ - -
From 000000
t
o 010011
Range is from –9.5dB to +9.5dB in 0.5dB
increments.
For exampl
e: -2.5dB = 000101, and set sign to (-).
CH2 RECEIVE LEVEL
For exampl
e: +3.5dB = 000111, and set sign to (+).
B 0 0 0 0 0 0 0 0
- - - - - - ↑ -
… For future use
B 0 0 0 0 0 0 0 0
- - - - - - - ↑
… For Future use
>> ta
ble continues on next page <<
