2. Attach the seals (provided with the new waste toner bottle) [A] to the five sponge pads.
This closes the waste toner bottle.
3. Release the lock [B].
4. Remove the waste toner bottle [C].
5. Put the waste toner bottle [C] into the supplied plastic bag to prevent toner from leaking
out of the bottle, and then seal the bag.
Toner Supply Tube
1. Remove the toner bottles.
2. Open the upper cover.
3. Clean each toner hopper entrance [A] with a vacuum cleaner.
4. PCDUs (page 106)
Image Creation
111
