Ricoh Aficio SP C440DN

Image Transfer
ITB (Image Transfer Belt) Unit
1. Open the left cover.
2. Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B].
3. Turn the ITB lock lever [A] counterclockwise.
4. Open the front door [A].
• Opening the front door [A] automatically releases the lock [B] for the ITB unit.
Image Transfer
125
