• The installation status of this option cannot be checked in the “Configuration Page”.
What Do the LED Indications Mean?
When this option is properly installed and recognized by the main machine, the LED indicators light up
under the following conditions.
No. Light Color Lights Up When:
1 Green and Yellow 1000BASE-T operates
2 Green 10BASE-T operates
3 Yellow 100BASE-TX operates
[Notes for Energy Save Mode Setting]
If the machine which has this option enters into the energy save mode, you cannot print because there
will be a communication error. Follow the instructions below to disable the machine’s entering into the
energy save mode.
1. Press [Menu] on the operation panel.
2. Select [System], and then press [OK].
3. Select [Engy Sv Md to Dsbl Prt Srv], and then press [OK].
4. Select [Disable Mode], and then press [OK].
5. Press [Escape] to go back to the main menu.
2. Installation
78
