SD Card Slots
• Slot 1 [1] is used for “Camera Direct Print Card Type P7”, “IPDS Unit Type P7”, “XPS Direct Print
Option Type P7”, “SD CARD SET FOR FONT TYPE D FOR MFP” or “VM CARD Type P7”.
• Slot 2 [2] is used for installing one of the optional applications for service only (for example,
updating the firmware).
Installation Procedure for USB Device Server Option Type M12
Component Check
No Items Q’ty Remark
1 Interface Board 1
2 USB Cable 1
3 Ferrite Core 4
- Band 2 NA only
• An Ethernet cable is not packed with this option.
Controller Options
73
