Engine SP Mode Tables: SP1000
SP1-XXX (Feed)
1001 [LEdge Regist] Leading Edge Registration Adjustment
(Tray Location, Paper Type, Color Mode), Paper Type -> Plain, Middle Thick, Thick
1, Thick 2 or Thick3
Adjusts the leading edge registration by changing the registration motor operation
timing for each mode.
Increasing a value: an image is moved to the trailing edge of paper.
Decreasing a value: an image is moved to the leading edge of paper.
1-001-001 Tray:Plain *ENG [–9 to 9 / 3.8 / 0.1 mm/step]
1-001-002 Tray:MThick *ENG [–9 to 9 / -0.6 / 0.1 mm/step]
1-001-003 Tray: Thick1 *ENG [–9 to 9 / -1.8 / 0.1 mm/step]
1-001-004 Tray: Thick2 *ENG [–9 to 9 / -2.7 / 0.1 mm/step]
1-001-005 Tray: Thick3 *ENG [–9 to 9 / -2.4 / 0.1 mm/step]
1-001-006 Tray:Plain:1200 *ENG [–9 to 9 / 1 / 0.1 mm/step]
1-001-007 Tray:MThick:1200 *ENG [–9 to 9 / -0.7 / 0.1 mm/step]
1-001-008 Tray:Thick1:1200 *ENG [–9 to 9 / -0.1 / 0.1 mm/step]
1-001-009 By-pass: Plain *ENG [–9 to 9 / 3.8 / 0.1 mm/step]
1-001-010 By-pass: MThick *ENG [–9 to 9 / 0.4 / 0.1 mm/step]
1-001-011 By-pass: Thick 1 *ENG [–9 to 9 / -1.3 / 0.1 mm/step]
1-001-012 By-pass: Thick 2 *ENG [–9 to 9 / -2.1 / 0.1 mm/step]
1-001-013 By-pass: Thick 3 *ENG [–9 to 9 / -1.9 / 0.1 mm/step]
1-001-014 Bypass:Plain:1200 *ENG [–9 to 9 / 1 / 0.1 mm/step]
1-001-015 Bypass: MThck:1200 *ENG [–9 to 9 / 0.1 / 0.1 mm/step]
1-001-016 Bypass: Thck1:1200 *ENG [–9 to 9 / 0.1 / 0.1 mm/step]
1-001-017 Duplex: Plain *ENG [–9 to 9 / 3.9 / 0.1 mm/step]
