• When re-attaching the by-pass, tilt the by-pass tray as shown above, and then insert the peg
lock arms into the keyholes of the machine.
Duplex Entrance Sensor
1. Duplex unit (page 208)
2. Disconnect the connector and remove the ground screw.
4. Replacement and Adjustment
212
To Next Page
