2. BCU with bracket (page 240)
3. HVPS: T1T2 board ( x 6, x all)
HVPS: CB Board
• If the optional tray heater is installed in the machine, the HVPS: CB bracket may be still hot. Wait
until the HVPS: CB bracket cools before doing this procedure.
1. Rear cover (page 91)
2. Right cover (page 90)
3. Controller box (page 235)
4. Inner left lower cover (page 96)
