11. Turn the main switch off and on.
12. Copy the data from the SD card to the NVRAM (SP5-825-001) if you have successfully
copied them to the SD card.
13. Turn the main switch off. Then remove the SD card from SD card slot 2.
14. Turn the main switch on.
15. Specify the SP and UP mode settings.
16. Do the process control self-check.
NVRAM on the Controller
After Replacement of a Defective NVRAM
1. You need the factory settings sheet provided with the machine.
2. Turn the power on, enter the SP mode, and then do the factory settings.
3. Re-install security settings as required.
NVRAM Upload and Download
1. Make sure that you have the SMC report (factory settings). This report comes with the
machine.
2. Output the SMC data (SP5-990-001) if possible.
3. Turn the main switch off. Then unplug the power cord.
4. Turn the main switch on.
5. Copy the NVRAM data (SP5-824-001) and the address book data in the HDD
(SP5846-051) to an SD card if possible.
• An error message appears if local user information cannot be stored in an SD card because
the capacity is not enough.
• You cannot do this procedure if the SD card is write-protected.
6. Enter SP mode. Then print out the SMC reports (SP5-990-001) if possible.
7. Turn off the main switch. Then unplug the power cord.
8. Replace the NVRAM on the controller. Then reassemble the machine.
9. Plug in the power cord. Then turn the main switch on.
10. Check if the serial number appears on the operation panel (SP5-811-002). Input the serial
number if it does not appear. (Contact your supervisor about this setting.)
4. Replacement and Adjustment
246
