2. Toner supply fan [A] ( x 2, x1)
When installing the toner supply fan
Make sure that the toner supply fan is installed with its decal facing to the left of the machine.
Toner Supply Fan Base
1. Right cover (page 90)
2. Toner supply fan base [A] ( x 2, x1)
Drum Motor: CMY
1. Right cover (page 90)
2. Toner supply fan base (page 151 "Toner Supply Fan")
4. Replacement and Adjustment
152
