BCU with bracket Removed
[G] HVPS: T1T2 Board
HDD (Option)
• Before replacing the HDD, copy the address book data to an SD card with SP5-846-051 if
possible.
• If the customer is using the Data Overwrite Security or the Data Encryption feature, these
applications must be installed again.
1. Grasp the handles [A], and then pull out the controller unit [B] (knob screw x 2).
Electrical Components
229
