Ricoh Aficio SP C440DN

2. Top cover (page 92)
3. Open the left cover.
4. Inner left upper cover [A] ( x 2)
Inner Left Front Cover
1. Left cover (page 89)
2. Inner left upper cover (page 94)
3. Inner left lower cover (page 96)
4. Turn the lock lever [A] counterclockwise, and then open the drum securing plate [B].
Exterior Covers
95
