1. Lubricate a part of the surface of the image transfer belt [A] with yellow toner, and then
turn the image transfer belt to the position [B] as shown above.
• Be sure to use yellow toner for the Z-P2; do not use lubricant powder, developer, or waste
toner.
• You can also use the provided service part: D0159500 (G104 Yellow Toner)
2. Install the ITB cleaning unit [A], and then collect the yellow toner by turning the image
transfer belt [B].
ITB Contact Motor
1. Right cover (page 90)
Image Transfer
133
