2. Right cover (page 90)
3. Controller box (page 235)
4. Development fan duct (page 123 "Development Fan")
5. Bracket [A] ( x 1)
6. Pull out the laser unit [A] ( x 2, x 1, x 1).
After installing a new laser unit
Do the following adjustment after installing the new laser unit.
4. Replacement and Adjustment
102
