Machine Level
Front to back: Within 5 mm (0.2")
Right to left: Within 5 mm (0.2")
Machine Space Requirements
• This machine, which uses high voltage power sources, can generate ozone gas. High ozone
density is harmful to human health. Therefore, the machine must be installed in a well-ventilated
room.
A: Over 500 mm (19.7")
B: Over 20 mm (0.8")
C: Over 100 mm (4.0")
D: Over 700 mm (27.6")
Above the machine: Over 350 mm (13.8")
Put the machine near the power source with the clearance.
2. Installation
30
