Ricoh Aficio SP C440DN

3. Tilt the by-pass tray as shown below.
4. Release the right inner large peg [A] first, and then left inner large peg [B].
5. Tilt the by-pass tray [A] as shown below, and then pull the by-pass tray.
• Tilting the by-pass tray rotates the peg lock arms [B] down so they can be removed from the
keyholes.
Duplex Unit
211
