• Make sure that the clip [A] does not fall inside the machine during maintenance.
20. Turn the toner tube [A] as shown above.
21. Pull out each toner supply tube [A].
• Clean each toner tube entrance with a vacuum cleaner.
• Work carefully when removing the toner supply tube [A] to avoid spilling toner on clothing or
the hands.
• Do not push the tip [A] of the toner tube because this will spill toner.
4. Replacement and Adjustment
116
