• Work carefully when releasing the toner supply tubes to avoid spilling toner on clothing or the
hands.
19. Gear unit [A] with the toner supply tubes for M, C and K ( x 6).
20. Remove the toner supply tubes for M, C and K [A] from the gear unit [B].
• Work carefully when removing the toner supply tubes [A] to avoid spilling toner on clothing or
the hands.
4. Replacement and Adjustment
150
