1-902-002 Result *ENG [0 to 3 / 0 / 1/step]
Displays the result of drum phase
adjustment.
0: Successfully done
2: Sampling failure
3: Insufficient detection number
1-902-003 Auto Execute *ENG [0 or 1 / 1 / 1/step]
Turns the automatic drum phase
adjustment on or off.
0: Off, 1: On
1907 [Feed Timing Adj.] DFU
Paper Type -> Pln: Plain, Thk: Thick
Line Speed -> Low: 85 mm/s, High: 260 mm/s, Middle: 182 mm/s
Parts Name -> F-: Feed, J-Gt: Junction Gate, SOL/Sol: Solenoid, CL: Clutch, STM:
Stepping Motor, Tr: Tray, F-On: Feed On Timing
1-907-001 F-Solenoid ON:Pln *ENG [-10 to 40 / 0 / 2.5 mm/step]
1-907-002 F-STM OFF: Plain *ENG [-10 to 10 / 0 / 1 mm/step]
1-907-003 F-STM ON: Plain *ENG
1-907-004 F-Solenoid ON:Thk *ENG [-10 to 40 / 0 / 2.5 mm/step]
1-907-005 F-STM OFF: Thick *ENG [-10 to 10 / 0 / 1 mm/step]
1-907-006 F-STM ON: Thick *ENG
1-907-007 F-START : Low *ENG
1-907-014 Bypass Sol ON:Low *ENG [-10 to 40 / 0 / 1 mm/step]
1-907-015 Bypass Sol ON:Mid *ENG
1-907-016 Bypass Sol ON:Hi *ENG
5. System Maintenance Reference
294
