2-104-001 LD1: K *ENG [60 to 140 / 100 / 0.1 %/step]
2-104-002 LD2: K *ENG
2-104-003 LD1: C *ENG
2-104-004 LD2: C *ENG
2-104-005 LD1: M *ENG
2-104-006 LD2: M *ENG
2-104-007 LD1: Y *ENG
2-104-008 LD2: Y *ENG
2109 [Test Pattern]
Generates the test pattern.
2-109-003 Pattern Selection ENG [0 to 23 / 0 / 1/step]
0 None
1: Vertical Line (1dot)
2: Vertical Line (2dot)
3: Horizontal (1dot)
4: Horizontal (2dot)
5: Grid Vertical Line
6: Grid Horizontal Line
7: Grid pattern Small
8: Grid pattern Large
9: Argyle Pattern Small
10: Argyle Pattern Large
11. Independent Pattern (1dot)
12. Independent Pattern (2dot)
13. Independent Pattern (4dot)
14. Trimming Area
15: Hound's Tooth Check (Vertical)
16: Hound's Tooth Check (Horizontal)
17: Band (Vertical)
18: Band (Horizontal)
19: Checker Flag Pattern
20: Grayscale Vertical Margin
21: Grayscale Horizontal Margin
22: Two Beam
23: Full Dot Pattern
2-109-005 Color Selection ENG Specifies the color for the test pattern.
[1 to 4 / 1 / 1/step]
1: All colors, 2: Cyan, 3: Magenta, 4:
Yellow
